WSN3045TY High Precision Woodworking Sliding Table Saw 3000x375 mm Dimensions

Product Details

Place of Origin: Shandong,China

Brand Name: TEING

Payment & Shipping Terms

Price: $2,400.00/sets 1-4 sets

Packaging Details: Export Standard Plywood Case

Supply Ability: 2000 Set/Sets per Year

Get Best Price

Product Details

Product Description

Highlight:

Condition:	New	Type:	Panel Saw
Use:	Woodworking, Wood Cutting, Wood Plate Slotting	Style:	Horizontal
Usage:	Woodworking, Wood Cutting, Wood Plate Slotting	Voltage:	380V/50HZ/3PH, Or Customized
Dimension(LWH):	280011001000mm	Warranty:	12 Month
Application:	Furniture Factory, Woodworking Factory, Home Use, Manufacturing Plant, Building Material Shops, Machinery Repair Shops, Construction Works	Weight (KG):	650 KG
Power (kW):	4KW+0.75KW/5.5KW+1.1KW	Key Selling Points:	High-accuracy
Max.Cutting Height At 90°(mm):	80mm	Max.Cutting Height At 45°(mm):	55mm
Max. Length Of Workpiece (mm):	2800mm	Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Marketing Type:	Hot Product 2020	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	1 Year
Core Components:	Motor	MAX. Cutting Width:	1250MM
Saw Blade Diameter:	300MM	Scoring Saw Blade Diameter:	120MM
Main Saw Spindle Speed:	3000/4000/5000 Rpm	Scoring Saw Spindle Speed:	7000/8000 Rpm
Spindle Saw Diameter:	30 Mm	Scoring Spindle Saw Diameter:	20 Mm
Keyword:	Woodworking Machine	Dimensions Sliding Table:	3000x375 Mm
Name:	Precision Panel Saw	Port:	Qingdao, China

Condition:	New
Type:	Panel Saw
Use:	Woodworking, Wood Cutting, Wood Plate Slotting
Style:	Horizontal
Usage:	Woodworking, Wood Cutting, Wood Plate Slotting
Voltage:	380V/50HZ/3PH, Or Customized
Dimension(LWH):	280011001000mm
Warranty:	12 Month
Application:	Furniture Factory, Woodworking Factory, Home Use, Manufacturing Plant, Building Material Shops, Machinery Repair Shops, Construction Works
Weight (KG):	650 KG
Power (kW):	4KW+0.75KW/5.5KW+1.1KW
Key Selling Points:	High-accuracy
Max.Cutting Height At 90°(mm):	80mm
Max.Cutting Height At 45°(mm):	55mm
Max. Length Of Workpiece (mm):	2800mm
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Marketing Type:	Hot Product 2020
Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year
Core Components:	Motor
MAX. Cutting Width:	1250MM
Saw Blade Diameter:	300MM
Scoring Saw Blade Diameter:	120MM
Main Saw Spindle Speed:	3000/4000/5000 Rpm
Scoring Saw Spindle Speed:	7000/8000 Rpm
Spindle Saw Diameter:	30 Mm
Scoring Spindle Saw Diameter:	20 Mm
Keyword:	Woodworking Machine
Dimensions Sliding Table:	3000x375 Mm
Name:	Precision Panel Saw
Port:	Qingdao, China

WSN3045TY High Precision Woodworking Sliding Table Saw 3000x375 mm Dimensions

Product Overview

Technical Data Sheet

Model	WSN3045TY	Dimensions sliding table	3000x375 mm
MAX. Cutting length	2900 mm	MAX. Cutting width	1250 mm
Saw blade Diameter	300 mm	Scoring saw blade diameter	120 mm
Max. Cutting Thickness	80mm	Main saw spindle speed	3000/4000/5000 rpm
Scoring saw spindle speed	7000/8000 rpm	Spindle saw diameter	30 mm
Scoring spindle saw diameter	20 mm	Tilling saw blade	0-45°
Main motor power	4 KW/5.5KW	Scoring motor	0.75KW/1.1KW
Weight	700 KGS	Voltage	380/220V or customizied
Main balde up and down	Manual	Overall dimensions	280011001000 mm

Details Images

Product packaging

Exhibition

Company Profile

Qingdao Skyyi Hengtong Machinery Equipment Co.,Ltd is one of the leading manufacturer in the woodworking machinery of China. We have 10000sqm factory and well-known "TEING" brand of sliding table saw, edge banding machine, sanding machine and so on.
With more than 10 years in woodworking machine industry, our machine had sold out to more than 20 Chinese Province, and more than 30 countries and regions, such as: Vietnam, Malaysia, USA, Canada, Brazil, Preu, Pakistan, Russia, Ukraine, India, Uzbekistan, Israel, Yemen, Thailand, Mexico, Ecuador and so on.
We passed the ISO 9001:2008, SGS and other certification, we believe through our efforts to make "TEING" grow up to world famous brand in order to serve worldwide woodworking industry with our quality products.
